Bean Bag Snag Tester AG13
Bean Bag Snag Tester is used to determine the snagging and picking resistance of knitted and woven fabric.
+8615280858852
ICI mace snag tester applies to rapid determine the snag resistance of fabric, (pull yarn loops from fabric). And suitable for woven and knitted fabrics made by textured yarn, non-textured yarn, and spun yarn, etc.
model :
AG07Brand:
AVENOorigin:
ChinaLead Time:
10-20daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE, ISO9001, ISO17025standard:
ASTM D3939, GB/T 11047, JIS L1058.
AG07-ICI Mace Snag Tester
Application Of ICI Mace Snag Tester
ICI mace snag tester applies to rapid determine the snag resistance of fabric, (pull yarn loops from fabric). And suitable for woven and knitted fabrics made by textured yarn, non-textured yarn, and spun yarn, etc.
Standards Of ICI Mace Snag Tester
ASTM D3939, GB/T 11047, JIS L1058.
Key Specification Of ICI Mace Snag Tester
Mode |
AG007-1 |
AG007-2 |
Test position |
2 |
4 |
Test speed |
60±2 r/min |
|
Testing Cylinder |
φ82mm, width 210mm |
|
Mace ball |
Weight 160±10g, 11mace |
|
Mace |
Length 10±1, Tip radius R0.13mm |
|
Felt thickness |
3-3.2mm, Width 165mm |
|
Guide rod working width |
125mm |
|
Distance between nail hammer and guide rod |
45mm |
|
Counter |
0-9999 |
|
Power Supply |
AC220V, 50/60HZ |
