BALLY Water Penetration Tester is used to measure the flexing resistance of shoe's upper materials.
model :
AF20Brand:
AVENOorigin:
ChinaLead Time：
10-20daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE ISO9001 ISO17025standard:
DIN 53338, ISO 5403, EN ISO 20344, QB/T 4044, BS EN 13518, EN 344-1, DIN 53338, ISO 17702, SATRA TM 171, EN 20344AF20 BALLY Water Penetration Tester
Application Of BALLY Water Penetration Tester
BALLY Water Penetration Tester is used to measure the flexing resistance of shoe's upper materials such as leather, symethetic leather and cloth immersed in water in order to be a valuable reference for research, waterproof treatment and quality improvement.
Standards Of BALLY Water Penetration Tester
DIN-53338, ISO 5403-1 2011, EN ISO 20344:2002(6.13), QB/T 4044, BS EN 13518-2002, EN 344-1:1992(5.14), DIN 53338, ISO 17702-2003, SATRA TM 171:1995, EN 20344:2004
Key Specification Of BALLY Water Penetration Tester
|
Model |
AF20 BALLY Water Penetration Tester |
|
Control mode |
Touch screen control |
|
Test position |
4 |
|
Test displacement |
0-6mm, can be set |
|
Speed |
60r/min, can be set |
|
Cylinders distance |
40mm |
|
Cylinder diameter |
30mm |
|
Power supply |
AC220V. 50/60HZ |
|
Dimension |
50×42×39cm |
|
Weight |
50kg |
Accessories Of BALLY Water Penetration Tester
|
Standard Accessories |
Standard water absorbent |
8pcs |
|
Sample cutting blade |
1pc |
|
|
80# sand paper |
5pcs |
|
|
200g weight |
1pc |
