Lea Strength Tester AY16

Lea Strength Tester AY16

Lea Strength Tester is used to test lea strength of different kinds of yarn, also can test pure and blending yarn of Cotton, wool, chemical fiber.

  • model :

    AY16
  • Brand:

    AVENO
  • origin:

    China
  • Lead Time:

    10-20days
  • port:

    Xiamen port
  • Payment:

    T/T, L/C
  • certificate:

    CE ISO9001 ISO17025
  • standard:

    GB/T 8696, ISO 6939
  • Product Detail

AY16-Lea Strength Tester


Application Of Lea Strength Tester

Lea Strength Tester is used to test lea strength of different kinds of yarn, also can test pure and blending yarn of Cotton, wool, chemical fiber.

  1. LCD controller, analysis of test results provides test data.
  2. AC servo drive for wide range speed setting
  3. Can connect to PC and printer, can get breaking strength and elongation at any point.


Standards Of Lea Strength Tester

GB/T 8696, ISO 6939


Key Specification Of Lea Strength Tester

Model

AY16 Lea Strength Tester

Control mode

LCD control

Strength capacity

0-2500N

Test precision

≤0.2%F·S

Test speed

10-600mmmin

Effective stroke

120mm

Clamp distance

50-500mm

Yarn hook width

8, 12, 16, 20, 24, 28, 32

Power supply

AC220V, 50/60HZ

Dimension

50*50*140cm

Weight

145kg
