Mouth-actuated Toys Endurance Tester is used to test the safety performance of mouth-actuated toys.
model :
AT26Brand:
AVENOorigin:
ChinaLead Time：
3-7 daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE ISO9001 ISO17025standard:
EN-71-1, ISO 8124-1, ASTM F963, GB 6675.2AT26-Mouth Toy Endure Tester (Mouth-actuated Tester)
Application Of Mouth Toy Endure Tester (Mouth-actuated Tester)
Mouth-actuated Toys Endurance Tester is used to test the safety performance of mouth-actuated toys.
Principle Of Mouth Toy Endure Tester (Mouth-actuated Tester)
The Mouth-actuated Toys Endurance Tester blows out and inhales a certain volume of gas of the toy at a certain speed for 10 times. After testing, determination if the toy and the parts spliting away off are small parts.
Standards Of Mouth Toy Endure Tester (Mouth-actuated Tester)
EN-71-1 section 8.17.2
ISO 8124-1 section 5.20
ASTM F963 section 8.13
GB 6675.2 section 5.20
Product Details Of Mouth Toy Endure Tester (Mouth-actuated Tester)
Key Specification Of Mouth Toy Endure Tester (Mouth-actuated Tester)
|
Model |
AT26 Mouth Toy Endure Tester (Mouth-actuated Tester) |
|
Test speed |
≥20r/min |
|
Test times |
10 times, can be set |
|
Test air pressure |
13.8Kpa, can be set |
|
Counting |
0~9999 times, can be set |
|
Barometer |
Digital display. Unit: Kpa, positive and negative pressure display |
|
Power Supply |
AC 220V 50/60Hz 3A |
|
Dimension |
22x56x30cm |
|
Weight |
35kg |
Accessories Of Mouth Toy Endure Tester (Mouth-actuated Tester)
|
Standard Accessories |
Test rubber tube 3size |
1pc/size |
|
Power |
1pc |
