TS7600 Spectrophotometer AC27

Model

AC27-TS7600 Spectrophotometer

lighting system

D/8 (stray lighting. 8°direction received);
SCI/SCE measure, exclusion UV measurement
Standard: CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7

Integral ball size

Φ40mm

Lighting source

Combined full spectrum LED light source

Spectrometry

Plane grating spectrometer

Inductor

Silicon photodiode array (double column 40)

Measuring wavelength range

400~700nm

Wavelength interval

10nm

half-band width

10nm

Test range of reflectance

0~200%

Measuring aperture

Customized single caliber: MAV:Φ8mm/Φ10mm；SAV: Φ4mm/Φ5mm

Optical mode

Test at same time, SCI/SCE

Color space

CIE LAB, XYZ, Yxy, LCh, CIE LUV, s-RGB, βxy, Munsell(C/2)

Color difference formula

ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc (2:1),ΔE*cmc(1:1),ΔE*00

Other chromaticity indicators

WI(ASTM E313，CIE/ISO, AATCC, Hunter)，
YI(ASTM D1925，ASTM 313),

Colour fastness of color staining, colour fastness color changing, strength, shade ,8 degrees gloss

Observer angle

2°/10°

Observation light source

D65,A,C,D50,F2(CWF),F7(DLF),F10(TPL5),F11(TL84),F12(TL83/U30)

Test time

about1.5s (test SCI/SCE at same time about 3.2s)

Repetitiveness

Spectral reflectance: MAV/SCI, standard deviations within 0.1% (400~700nm：within 0.2%)：
chromatic value: MAV/SCI, ΔE*ab within 0.04 (After preheat correction, measure the average of whiteboard 30 times interval 5S)

Standard Accessories

Power adapter, data line, quality management software, black and white correction box, protective cover, wrist band, measuring caliber (ø8 or 4 mm caliber)

Option Accessories

Micro printers, powder test boxes
