Button Impact Resistance Tester is used to determine the impact resistance of plastic sew-through flange buttons.
model :
AG12Brand:
AVENOorigin:
ChinaLead Time：
10-20daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE ISO9001 ISO17025standard:
ASTM D5171AG12-Button Impact Resistance Tester
Application Of Button Impact Resistance Tester
Button Impact Resistance Tester is used to determine the impact resistance of plastic sew-through flange buttons. Individual buttons are placed on a surface centered under a tube through which a preselected mass falls from a preselected height. After the mass impacts the button the impacted button is removed and visually examined using a 5X magnifying glass for breakage, cracking, or chipping.
Standards Of Button Impact Resistance Tester
ASTM D5171
Key Specification Of Button Impact Resistance Tester
Model
AG12 Button Impact Resistance Tester
Material
Stainless steel
Impact Quality
0.84Kg
Testing Height
32mm. 44mm. 67mm. 83mm.
95mm. 117mm. 200mm
Dimensions
240*200*340mm
Weight
3kg
