Rubber Vertical Rebound Resilience Tester tests the elasticity of rubber materials by means of free falling hammer. Adjust the level of the instrument first, and then lift the drop hammer to a height of 400mm. When placing the test piece, pay attention to make the drop point 14mm from the edge of the test piece. The first three tests are not used, and the average rebound height of the fourth, fifth and sixth times are recorded.
model :
AF85Brand:
AVENOorigin:
ChinaLead Time：
3-7daysport:
Xiamen portPayment:
T/T, L/Ccertificate:
CE ISO9001 ISO17025standard:
ASTM D2632AF85-Rubber Vertical Rebound Resilience Tester
Application Of Rubber Vertical Rebound Resilience Tester
Rubber Vertical Rebound Resilience Tester tests the elasticity of rubber materials by means of free falling hammer. Adjust the level of the instrument first, and then lift the drop hammer to a height of 400mm. When placing the test piece, pay attention to make the drop point 14mm from the edge of the test piece. The first three tests are not used, and the average rebound height of the fourth, fifth and sixth times are recorded.
Standards Of Rubber Vertical Rebound Resilience Tester
ASTM D2632
Function Of Rubber Vertical Rebound Resilience Tester
2. Special fixture, high precision processing, beautiful appearance, durable
3. Customized printing ruler, easy to observe.
4. Linear guide rod, zero contact falling friction.
Key Specification Of Rubber Vertical Rebound Resilience Tester
|
Model |
AF85 Rubber Vertical Rebound Resilience Tester |
|
Falling height |
400mm |
|
Hamer weight |
28g |
|
Sample thickness |
12.5mm |
|
Dimension |
25*15*55cm |
|
Weight |
90kg |
